Hot Water Boilers

Features:

• 250kW Output
• Stackable Design
• Ability to cascade up to 12 FHE-250 models
• Allows up to 3000kW output (allowing up to 60:1 turn down ratio)
• Boiler Configuration is achieved using one
• ‘Master’ controller
• 95.9% Seasonal Boiler Efficiency
• Up to 95°C Flow Temperature
• All Stainless Steel Heat Exchanger is capable of supplying either LTHW (Low Temp. Hot Water) or DHW (Domestic Hot Water)
• Low NOx Burner <40mg/kWh (22.5ppm)
• Small Footprint
• 2 Year Warranty

This new highly-efficient FHE-250 low-temperature hot water boiler is initially available in a 250kW model and features a fully-condensing, stainless steel heat exchanger.

A modular approach to its design also means that additional boilers can be combined to suit any application and hot water requirement.

With the complexity of control being a criticism of many hot water boilers available on the market today, the new FHE uses a single control panel which is capable of controlling a single unit or a modular installation.
